Three Phase Open Frame Power Supply
- Unregulated DC output
- 480V, 3-phase input eliminates need for step-down trasformer
- Field selectable 430/460/480/500/530V input taps
- Operating Temprature: 0°C TO 40°C full rated load
- Finger-safe and creepage-proof screw terminal connections
Specifications
- AC Input: 430/460/480/500/530 VAC, 3 phase, 50/60 Hz
- DC Output: 24VDC
- Ripple: 5% r.m.s. maximum at nominal line and full load
- Operating Temprature: 0-40°C full rated load (Derate 2% per °C to 70°C)
- Overload and Short Circuit Protection: Fused Output
of 397
| Compare | Part No. | Case Size | Output/th> | UL File No. | RoHs | Datasheet | Quanitity Available | Check Price |
|---|---|---|---|---|---|---|---|---|
| BVZ-24TA5 | Data 2 | Data 3 | Data 4 | Data 5 | Data 6 | Data 7 | Data 8 | |
| Data 1 | Data 2 | Data 3 | Data 4 | Data 5 | Data 6 | Data 7 | Data 8 | |
| Data 1 | Data 2 | Data 3 | Data 4 | Data 5 | Data 6 | Data 7 | Data 8 |
